ISCA-5530762

Iscar 5530762 SCD-ACP3 Stub Length Screw Machine Drill With Internal Through Coolant 1/4 in Drill - Fraction 0.25 in Drill - Decimal Inch Solid Carbide TiAlN Coated

Iscar Screw Machine Drill Stub Length Series: SCD-ACP3 Imperial 1/4 in Drill - Fraction 0.25 in Drill - Decimal Inch 2.82 in Overall Length 3XD Cutting Depth 2 Flutes Spiral Flute 1.28 in Flute Length 1/4 in Shank Straight Shank Standard Point Right Hand Cutting Direction Solid Carbide Cutting Edge Solid Carbide TiAlN Coated Applicable Materials: Cast Iron Hard Materials High Temperature Alloy Stainless Steel and Steel

Call for inventory•8 days shipping

Details

  • IC908 Grade - A hard fine grain substrate with excellent chipping resistance combined with a TiAlN PVD coating Provides high wear and oxidation resistance Recommended for a very wide range of materials applications and machining conditions ANSI Code: SCD 0250-128-0250ACP3 IC908

Attributes

  • Applicable Materials: Cast Iron Hard Materials High Temperature Alloy Stainless Steel and Steel
  • Cutting Direction: Right Hand
  • Cutting Edge Material: Solid Carbide
  • Finish: TiAlN Coated
  • Flute Length: 1.28 in
  • Material: Solid Carbide
  • Overall Length: 2.82 in
  • Point Type: Standard
  • Shank Type: Straight
